Rotary Laser FRE-301

SOUTHGEOSYSTEMS
FRE301-A300196
kg
Add to cart
  • Description
  • Future

Red/Laser, 600 Range, 1mm accuracy, +/- 10% Slope, 30mt Remote control 30hrs - IP65

SOUTHGEOSYSTEMS MEASURING INSTRUMENT
Standard Pack: LASER, Hard Carry Case, Radiation-proof Glass (Protection & Visibility Increase), Magnetic Laser Targets, Remote Control,NIMH battery packs, Operating Manual, Charger& Adaptor, one laser detector with mount-holder (FRD100). l Suggested Accessories: Tripod/ Grade Rod/ Ceiling Bracket / Upgrade to FRD400 detector for more functions of detecting(detail refer to accessories part)

Shocking Alert function/ Anti-wind model
Can be used for both horizontal and vertical application.
Accuracy: H: ±20″(1mm in 10m), V: ±20″(1mm in 10m)
Manual Function allows easy slope/ Gradient job sites.
Manual Slope Function: ± 10%
Compensation Self-leveling Range: 5º
Measuring Range Diameter: Min 400m (With laser detector)
Spinning Speed 60、120、300、600 r.p.m. l Direction scanning: 10°;45°;90°;180°
Remote Distance: Approximately 30m indoor / 10m outdoor, depending on operating position.
Power supply: NI-MH Rechargeable -Battery
Continuous Working Hrs: 40hrs, depending on operating condition.
Operating Temperature: -20℃-- +50℃(-4ºF-- +122ºF) l IP: 54 l
